Dimensions (LxWxH): 600 x 400 x 550mm (23.6" × 15.7" × 21.7")
• Height with Cabinet: 1,360mm/53.5"
• Display Volume: 111 L/29.4 gals
• Glass Thickness: 8mm (5/16")
• EDEN Complete Includes: Aquarium, Cabinet
Amazingly Clear Display Panels
The EDEN is manufactured to the same quality you would expect from our master technicians, the Waterbox Aquariums® quality stands out above the rest. Utilizing ultra-clear glass, each EDEN aquarium offers the most transparent viewing experience possible.quality stands out above the rest. Ultra-clear glass displays offer 91% light Transmittance and complete visual clarity up to 19mm (3/4”)
Technical Specifications
| PRODUCT MODEL | EDEN 20 | EDEN 30 | EDEN 40 | |
|---|---|---|---|---|
| System | System Length | 450mm/17.7" | 600mm/23.6" | 800mm/31.5" |
| System Width | 450mm/17.7" | 400mm/15.7" | 400mm/15.7" | |
| System Height (with Cabinet) | 1,260mm/49.6" | 1,360mm/53.5" | 1,360mm/53.5" | |
| Aquarium | Dimensions | 450 x 450 x 450mm | 600 x 400 x 550mm | 800 x 400 x 550mm |
| 17.7" × 17.7" × 17.7" | 23.6" × 15.7" × 21.7" | 31.5" × 15.7" × 21.7" | ||
| Aquarium Volume | 77 L/20.2 gals | 111 L/29.4 gals | 150 L/39.5 gals | |
| Glass Thickness | 6mm (1/4") | 8mm (5/16") | 8mm (5/16") | |
| Glass Material | Ultra-clear Low Iron glass | |||
| Transmittance | 91% | |||
| Joints | Regular 90° | |||
| Tank Lid | 5mm Black Glass | |||
| Max Water Level | 404mm (15.9") | 504mm (19.8") | 504mm (19.8") | |
| Max LED Lighting Length | 438mm (17.2") | 584mm (23") | 784mm (30.9") | |
| Min LED Lighting Length | 388mm (15.2") | 534mm (21") | 734mm (28.9") | |
| Max LED Lighting Thickness | 19mm (3/4") | 19mm (3/4") | 19mm (3/4") | |
| Max Canister Filter Piping | DN15 (20mm/3/4") | DN15 (20mm/3/4") | DN20 (25mm/1") | |
| Vinyl on Rear Glass | Black for BLK, White for WHT and ASP | |||
| Silicone Color | Black for BLK, Clear for WHT and ASP | |||
| Top Banding Width | 60mm (2.4") | |||
| Bottom Banding Width | 40mm (1.5") | |||
| EVA Mat (Black) | x 1 | |||
| Cabinet | Cabinet Model | PB 1818 | PB 2416 | PB 3216 |
| Cabient Dimensions | 450 x 450 x 810mm | 600 x 400 x 810mm | 800 x 400 x 810mm | |
| 17.7"×17.7"×31.9" | 23.6"×15.7"×31.9" | 31.5"×15.7"×31.9" | ||
| Cabinet Material | 18mm Particle Board, PVC Laminated | |||
| Cabinet Color | WHT-White, BLK-Black, ASP-Aspen | |||
